UL Certification ASTM A795 Black and Hot Dipped Zinc-Coated(Galvanized)Welded fire protection pipes

Name: UL Certification ASTM A795 Black and Hot Dipped ZincCoatedGalvanizedWelded fire protection pipes
Brand: Torich
Price: 600 USD

China UL Certification ASTM A795 Black and Hot Dipped Zinc-Coated(Galvanized)Welded fire protection pipes wholesale

Brand Name : Torich

Model Number : ASTM A795

Certification : ISO9001 TS16949

Place of Origin : China

MOQ : 5 tons per year

Price : 600-1000USD/ton

Payment Terms : L/C, T/T

Supply Ability : 5000tons per year

Delivery Time : 5-8 week days

Packaging Details : In bundles

Standard : ASTM A795

Material : GrA and GrB

OD : 1/2"-10”

WT : 2.77-7.80mm

Length : 12m max

Produce method : Welded or Seamless

Contact Now

ASTM A795 Black and Hot Dipped Zinc-Coated(Galvanized)Welded fire protection pipes (Fire Sprinkler Pipe)

Quick detail

Standard	ASTM A795
Material	GrA and GrB
OD	1/2"-10”
WT	2.77-7.80mm
Length	12m max
Produce method	Welded or Seamless
Anticorrosive	1. hot galvanized; 2. powder coating; 3.painting
End	1.Grooved; 2. Plain end; 3.screwed & socketed
Function	Fire and water supply system in building

Detail description:

ASTM A795 steel pipe(A fire sprinkler pipe )is the component of the fire fighting sprinkler system that discharges water when the fire had been detected that the temperature exceeded the predetermined temperature. The fire sprinkler piping is extensively used worldwide. There are several sprinklers provided by the fire sprinkler pipe suppliers, like quick response, standard response, CMSA, residential, ESFR.

ASTM A795 (BLACK & GALVANISED)

N.D.		O.D.		SCH 10				SCH 30/40
N.D.		O.D.		WALL THICKNESS		NOMINAL WEIGHT		WALL THICKNESS		NOMINAL WEIGHT
(mm)	(inch)	(mm)	(inch)	(mm)	(inch)	(kg/mtrs)	(lbs/ft)	(mm)	(inch)	(kg/mtrs)	(lbs/ft)
15	1/2	21.30	0.84	----	----	----	----	2.77	0.109	1.27	0.85
20	3/4	26.70	1.05	2.11	0.083	1.28	0.96	2.87	0.113	1.69	1.13
25	1	33.40	1.32	2.77	0.109	2.09	1.41	3.38	0.133	2.50	1.68
32	1-1/4	42.20	1.66	2.77	0.109	2.69	1.81	3.56	0.14	3.39	2.27
40	1-1/2	48.30	1.90	2.77	0.109	3.11	2.09	3.68	0.145	4.05	2.72
50	2	60.30	2.38	2.77	0.109	3.93	2.64	3.91	0.154	5.45	3.66
65	2-1/2	73.00	2.88	3.05	0.12	5.26	3.53	5.16	0.203	8.64	5.80
80	3	88.90	3.50	3.05	0.12	6.46	4.34	5.49	0.216	11.29	7.58
90	3-1/2	101.60	4.00	3.05	0.12	7.41	4.98	5.74	0.226	13.58	9.12
100	4	114.30	4.50	3.05	0.12	8.37	5.62	6.02	0.237	16.09	10.80
125	5	141.30	5.56	3.4	0.134	11.58	7.78	6.55	0.258	21.79	14.63
150	6	168.30	6.63	3.4	0.134	13.85	9.30	7.11	0.28	28.29	18.99
200	8	219.10	8.63	4.78	0.188	25.26	16.96	7.04	0.277	36.82	24.72
250	10	273.10	10.75	4.78	0.188	31.62	21.23	7.08	0.307	51.05	34.27

UL Certification ASTM A795 Black and Hot Dipped Zinc-Coated(Galvanized)Welded fire protection pipes

UL Certification ASTM A795 Black and Hot Dipped Zinc-Coated(Galvanized)Welded fire protection pipes Images
